BITOP 48-cavity PET bottle preform injection mould. See the photographed tooling and discuss preform weight, neck finish, hot runner and machine fit.
PRODUCT / PN000205
BITOP 48 Cavity PET Preform Mould
This BITOP catalogue example shows a 48-cavity injection mould for PET bottle preforms for beverage-container production. The mould is custom-engineered to the agreed part drawing and injection-moulding setup.
- Mould cavities
- 48
- Product application
- PET bottle preform
- Manufacturing process
- Injection moulding
Illustrated catalogue configuration. Final construction and performance are defined by the customer-approved drawing.
PRODUCT DETAILS
Mould Overview
The 48-cavity example is shown with two views of a preform injection mould.
The pet bottle preform shown here is one illustrated configuration. The finished mould must be matched to the required part dimensions, material and production equipment.
Catalogue Mould and Application Images
Catalogue Technical Details
| Mould category | Plastic injection mould |
|---|---|
| Application | PET bottle preform |
| Catalogue cavities | 48 |
| Illustrated example | 48 Cavity Preform Mould |
Catalogue Range and Project Requirements
BITOP states that its preform injection-mould engineering covers 1 to 64 cavities. The brochure also gives a 28 mm neck and 12.5 g preform as a section example; those figures are not expressly assigned to every pictured mould.
- Provide the finished part and neck-finish drawings, target cavity count and resin.
- Confirm the injection-machine interface, gate and cooling requirements before final mould design.
- Confirm preform weight, neck finish, bottle design and compatible injection machine for the requested 48-cavity configuration.
Request a Custom Mould Quotation
Send the part drawing, dimensions, material, required cavities and available injection-machine details. BITOP can then confirm the mould design, technical specification and quotation for your project.
