Low plastic stool injection mould, Design 2, illustrated with a rectangular seat and straight legs. Specify seat proportions, leg section, texture and service conditions.

PRODUCT / PN000233

Low Plastic Stool Injection Mould - Design 2

The illustrated mould is paired with a green low stool with straight legs and a rectangular seat. The finished examples show related low-stool surface treatments.

Application: Low plastic stool
Process: Injection moulding
Tooling specification: To the approved drawing

Compare moulds in this series

SEND AN INQUIRY WhatsApp +86 13566629430

PRODUCT DETAILS

Mould Overview

The illustrated mould is paired with a green low stool with straight legs and a rectangular seat. The finished examples show related low-stool surface treatments.

Specify the finished part drawing, selected plastic material and production requirements to develop tooling for this application.

Mould and Finished Product Examples

Low Plastic Stool Injection Mould - Design 2 - illustrated tooling photograph

Finished product application examples from the same catalogue series. Exact dimensions, material and configuration follow the approved project drawing.

Application and Tooling Details

Manufacturing process	Plastic injection moulding
Application	Low plastic stool
Illustrated part form	Rectangular seat with straight legs
Project specification	Customised to the approved part drawing and injection machine

Design Requirements

Discuss the following details when requesting a quotation for this low plastic stool mould:

Seat length, width and height
Leg section and seat-to-leg transitions
Surface texture and intended service conditions
Required cavity configuration and production target
Available injection-machine dimensions and interface

Mould steel, gate arrangement, cooling design and any performance targets are confirmed in the project specification.

Request a Mould Quotation

Send a part drawing or sample, the target dimensions and weight, plastic material, expected output and injection-machine details. These inputs allow the tooling scope and quotation to be defined.
